Mobile phone camera assembly guide system

(A) Project Background

With the rapid upgrading of 3C products, more and more new technologies are applied to them. Its production process automation speed is also high speed, the robot is the fastest development in the production of the past few years, with the support of the same visual are widely used.

In general, the accuracy of the assembly equipment, if simply from the body, clip on the transformation of a rule, will cost a considerable amount of cost, and the installation of accurate visual guidance agencies, on the other hand, Can be a very good solution to the problem.

(B) functional requirements

  Check if there is any material in the tray

  Guide the robot to grab the camera

  Guide the robot assembly mobile phone camera

  Check the fit position is correct

(C) system configuration

  POMEAS HD telecentric lens PMS-TC1-65

  Pumasi 500W Pixel Industrial Camera

  Industrial computer

  A Software System Based on

  Mitsubishi PLC

  Mitsubishi robot

(D) system characteristics

  For multi-camera requirements, based on PC-Based program, with a very high cost

  Customized graphical user interface, simple and easy to use

  Flexible hardware configuration, with a strong scalability

  Fitting accuracy of up to ± 0.03mm1
